X-CDU

Features X-CDU

X-CDU is a remote control interface for the Control Display Unit (CDU) present in X-Plane 11.
This app does not provide an FMS, but simply a way to control the existing CDU from an Android tablet or phone.
Aircraft support -Default X-Plane CDU-ToLiss A319 -ToLiss A321-ToLiss A340-FlightFactor 757 -FlightFactor 767 -FlightFactor 777 -FlightFactor A320-FlightFactor A350 -VMAX 787-Rotate MD-80-SSG 747-8 Series-Zibo Mod 737-800 -737-900 Ultimate-737-700 Ultimate-LevelUp 737NG-IXEG 737-300-JARDesign A320-JARDesign A330 -JARDesign A340-500 -Peters Aircraft A320The support may cause abnormal connection due to different versionsSSG Embraer 195 is for trial use only-Default X-Plane CDU includes atr72 mk787 EADT 737 MD82 xhangar G650 X-Rotors AW139.Wilsons aircraf 707Carenado - 390 PREMIER IACarenado - Falon 50EXCarenado - SAAB 340DMO S92 And other models I don’t know supports growing number of aircraftRequirements:- X-Plane 11- Export explane plugin from App to Android device X-CDU directory or Download the ExtPlane plugin from https://github.com/vranki/ExtPlane/releases and unzip it, copy the extracted directory into the Resources/Plugins directory- Make sure the plug-in contains the XPL file of the corresponding platform- Open TCP port 51000 in Windows firewall for ExtPlane- Multicast support on your Android device for auto-detectionX-CDU will auto-detect your X-Plane instance assuming that multicast is working.
Many routers or Android device do not support multicast properly, and so you can tap on the CDU screen top to configure a manual X-Plane IP address.You must have the ExtPlane plugin installed in your X-Plane 11 Resources/plugins directory.
This plugin uses port 51000 to provide external control capabilities, so you must make sure that Windows firewall is not blocking it .Remember: extract the plugin into your Resources/plugins directory, and make sure port 51000 is not blocked by the Windows firewall.-FlightFactor 777 need open 18387 port and Related CDU plug-ins-FlightFactor A320: need to set a user/pass in the EFB on tablet
